407Product Description:
The FGF Series of 3D printers is engineered for high performance, offering six key equipment advantages designed to improve print size, speed, reliability, and efficiency.
I. Six Major Equipment Advantages
1. Bigger Printing Space
Provides a maximum printing volume of up to 1500 × 1500 × 1200 mm.
2. Faster Printing
Delivers a productivity upgrade with a printing speed reaching 300 mm/s.
3. High-Temperature, High-Speed Printing
Features a standard maximum temperature of 500°C, with high-temperature resistance also up to 500°C.
4. Automatic Tuning Device
Prevents material overflow, reducing waste while saving time and labor.
5. Chamber Temperature Control
Maintains a 60°C constant temperature environment, enhancing the toughness and stability of printed parts.
6. Automatic Feeding
Precisely supplies materials to the system, reducing manual intervention and waiting time.
Technical Specifications
|
Item |
FGF1200 |
FGF1500 |
|
Molding technology |
Pellet FGF Fused Granule Fabrication |
Pellet FGF Fused Granule Fabrication |
|
Operating panel |
12-inch color capacitive touch screen |
12-inch color capacitive touch screen |
|
Forming size (LxWxH) |
1200x1200x1000mm |
1500x1500x1200mm |
|
External size (LxWxH) |
2200x2000x2300mm |
2500x2300x2300mm |
|
Working table temp. |
<=120C |
<=120C |
|
Working table contact surface |
Aluminum alloy platform |
Aluminum alloy platform |
|
Nozzle optional diameter |
2mm, 3mm, 4mm, 5mm |
2mm, 3mm, 4mm, 5mm |
|
Nozzle max temp. |
<=350C (over-temp customizable) |
<=350C (over-temp customizable) |
|
Automatic feeder |
Three-machine automatic conveyor |
Three-machine automatic conveyor |
|
Positioning accuracy |
0.02mm |
0.02mm |
|
Print layer height |
0.5-6mm (adjustable per customer needs) |
0.5-6mm (adjustable per customer needs) |
|
Print speed (Flow) |
5kg/h |
8kg/h |
|
Print flow rate |
100-300mm/s |
100-300mm/s |
|
Slicing support format |
STL (convertible formats OBJ/STP/3DS etc.) |
STL (convertible formats OBJ/STP/3DS etc.) |
|
Rated power |
7.5kW |
9kW |
|
Machine weight |
1200KG |
1500KG |
|
Drive mode |
Servo + Stepper motor |
Servo + Stepper motor |
|
Power voltage |
AC 380V |
AC 380V |
|
Selectable printing materials |
ABS/PC, ABS+GF, PETG, PETG+GF, ABS, PLA, PA66, PC/PC-GF/PA66 /PA12.GF/ABS/PLA |
ABS/PC, ABS+GF, PETG, PETG+GF, ABS, PLA, PA66, PC/PC-GF/PA66 /PA12.GF/ABS/PLA |
